Product Description
The Multi-jet water meter, with simple structure, stable measurement, and cost-effectiveness, is suitable for a wide range of water usage scenarios.
Product Features
- High Measurement Accuracy:
The multi-jet design allows water to strike the impeller from multiple directions, resulting in more uniform force on the impeller. This leads to higher measurement accuracy under various flow conditions, especially at low flow rates, making it more precise than single-jet water meters in measuring actual water usage.
- Low Pressure Loss:
As water flows through a multi-jet water meter, the flow channels are designed to be efficient, resulting in minimal resistance and lower pressure loss. This helps reduce energy loss in the pipeline system, ensures the normal operation of the water supply system, and lowers supply costs.
- High Reliability:
Made from high-quality materials with a well-designed structure, the meter offers excellent corrosion and wear resistance, allowing it to operate stably over long periods with a long service life.
- Wide Applicability:
It is suitable for a wide range of applications, including residential housing, commercial buildings, and agricultural irrigation. It can accurately measure different types of water and adapt well to varying water qualities and flow conditions.
- Technical data conforms to the international standard ISO 4064.
Overall dimension and weight
|
DN (mm) |
15 | 20 | 25 | 32 | 40 | 50 | 50 |
|
Size (inch)
|
1/2"
|
3/4
|
1"
|
1-1/4"
|
1-1/2"
|
2"
|
2"
|
|
Length (L)
|
165/190
|
190 | 260 | 260 | 300 | 300 | 280 |
|
Width (W)
|
98 | 98 | 103.5 | 103.5 | 125 | 125 | 160 |
|
Height (H)
|
116 | 117 | 124 | 124 | 162 | 162 | 187.5 |
|
Connecting
Thread D
|
G3/4B
|
G1B
|
G11/4B
|
G11/2B
|
G2B
|
G21/2B
|
Flange
end
|
Technical Data
| DN(mm) | 15 | 20 | 25 | 32 | 40 | 50 | |
|
Size(inch) |
1/2" |
3/4" |
1" |
1-1/4" |
1-1/2" |
2" |
|
|
Q4(l/h) |
3125 |
5000 |
7875 |
12500 |
20000 |
31250 |
|
|
Q3(l/h) |
2500 |
4000 |
6300 |
10000 |
16000 |
25000 |
|
| R=160 | Q2(l/h) | 25 | 40 | 63 | 100 | 160 | 250 |
| Q1(l/h) | 15.62 | 25 | 39.37 | 62.5 | 100 | 156.25 | |
| R=200 | Q2(l/h) | 20 | 32 | 50.4 | 80 | 128 | 200 |
| Q1(l/h) | 12.5 | 20 | 31.5 | 50 | 80 | 125 | |
|
Max. Reading (m3)
|
99,999
|
99,999
|
99,999
|
99,999
|
99,999
|
99,999
|
|
|
Min.Reading (Liter)
|
0.05
|
0.05
|
0.05
|
0.05
|
0.05
|
0.05
|
|
|
Accuracy Class
|
Class2
|
||||||
|
Temperature Class
|
T50/T90
|
||||||
|
Maximum Admissible
Pressure
|
PN16
|
||||||
|
Pressure Loss Classes
|
0.63bar
|
||||||
|
Pulse Output Option
|
Vmax=24V
|
||||||
|
Imax=100mA
|
|||||||
|
Pmax=2W
|
|||||||
