DN50 Electronic R50 Woltman Water Meter Flanges

DN50 Electronic R50 Woltman Water Meter Flanges

size: dn50-dn300
Material: Ductile iron
Send Inquiry

Hebei Shanghong Meters Technology Co., Ltd. is one of the leading manufacturers and suppliers of dn50 electronic r50 woltman water meter flanges in China. If you're going to wholesale high quality dn50 electronic r50 woltman water meter flanges, welcome to get pricelist and quotation from our factory.



There are 2 types of woltman water meters, LXLC with hub and LXXG with impeller

1

When there are many solid impurities in the water, you can use the LXXG type water meter, which can make the solid impurities easily pass through the water meter and avoid damage.

woltman water meter (3)

Type

Size

Length

Height

Connecting Flange

mm

D1 Outside Diameter

D2 Bolt Circle Diameter

Connecting Bolts(n-M)

LXXG-50

50

200

253

165

125

4-M16

LXXG-65

65

200

268

185

145

4-M16

LXXG-80

80

225

284

200

160

8-M16

LXXG-100

100

250

295

220

180

8-M16

LXXG-125

125

250

310

250

210

8-M16

LXXG-150

150

300

339

285

240

8-M20

LXXG-200

200

350

382

340

295

8-M20(1.0Mpa)

12-M20(1.6Mpa)

LXXG-250

250

450

438

395

350

12-M20(1.0Mpa)

405

355

12-M24(1.6Mpa)

LXXG-300

300

500

488

445

400

12-M20(1.0Mpa)

460

410

12-M24(1.6Mpa)

NOTE: The flange dimension conforms to ISO7005-1:1988 standard. Flange standard can be customized. Order for products of special requirements is also accepted

For more information about water meters, please contact us
