Automatic Ultrasonic Water Meter Test Benches For Ultrasonic Water Meters

Material: Stainless steel;
Type: Fully Automatic;
Model: SHA25-P-1;
MOQ: 1 set;
Features: Full automation, Small Volume, High Efficiency, Energy saving including water, electricity power, and manpower.
Function: test for water meter;
Size Rang: DN15mm-DN25mm (1 /2"-1-1/2") water meter;
Warranty: 1 year.

Send Inquiry

Hebei Shanghong Meters Technology Co., Ltd. is one of the leading manufacturers and suppliers of automatic ultrasonic water meter test benches for ultrasonic water meters in China. If you're going to wholesale high quality automatic ultrasonic water meter test benches for ultrasonic water meters, welcome to get pricelist and quotation from our factory.

AUTOMATIC WATER METER TEST BENCHES

Type	Water Meter Testing
Max Capacity	Dn25mm
Load Way	Electronic Load
Loading Method	Dynamic Load
Display	Digital
Control	Computer Control
Size	5800 mm 1500 mm 2500mm
Power Source	380V
Trademark	S.H.Meters
Transport Package	Wooden Case
Specification	ISO4064
Origin	Shijiazhuang, Hebei, China
Product Description	Water Meter Test Bench Automatic Test Bench

water meter test bench picture

Technical specification:

1. Accuracy class: ≤0.2

2. Water source pressure: 0.4-0.5Mpa Air source pressure: 0.4-0.6Mpa

3. Water flow rate range: 4-8000L/H

4. Working temperature: 0-50ºC

5. Water meter size and quantity: DN15(165mm)X5 pcs, DN20(190mm)X5pcs, DN25(260mm)X5pcs

6. Pressure withstanding testing range: 0.4~2.0Mpa

7. Clamping device: DiameterΦ25mm, distance 55mm

8. Weighting scale: TOLEDO (1)150KG, accuracy 1/3000 TOLEDO (2)30KG, accuracy 1/3000

9. Instantaneous flow meter: Glass rotor flow meter

10. Test bench controlled by PC system, collect, calculate, judge, output, and save data automatically. Can search and print through the label of time or meter no. etc. Adopt PLC as a logical processor and pulse collector, instead of traditional SCM, to ensure the stability of operation. PLC is programmable, high stability, and extendable; signal collecting speed is 10000 times/second, and processing speed can reach 0.35-1us.

11. Adopt a Panasonic laser sensor for data collection, collect frequency not less than 5000Hz, and has the feature of high stability and reliability.

12. Equipment adopts an aluminum ally for the frame structure.

13. Water pump: Grundfos is equipped with an inverter to realize water supply under constant pressure.

14. Stabilizer source: 0.15m³ stainless steel stabilizer device.

15. Equipped with Pressure sensor and temperature sensor

water meter test bench picture2
