Hebei Shanghong Meters Technology Co., Ltd. is one of the leading manufacturers and suppliers of mechanical brass pipe volumetric water meter maldives in China. If you're going to wholesale high quality mechanical brass pipe volumetric water meter maldives, welcome to get pricelist and quotation from our factory.

Features	Application
1. Low start-up flow rate. 2. Volumetric rotary piston principle of measurement. 3. LXHY-15~20 is no location limitation for installation.Accuracy is not to be affected wherever installed at a horizontal,vertical or inclined pipeline. 4. Register is sealed with a special liquid to keep a clear reading in long terrm service. 5. Mechanism use of high-quality rmaterial to ensure a stable characteristic. 6. Accurate measurement with conformity to lSo 4064 class c. 7. on request,the series can be equipped with a kind of remote transmission device.	Measuring the volume of cold portable water passing through the pipeline.Also suitable for pure water.
	Warranty
	- Water temperature:0.1℃~50℃C for cold water meter. .0.1℃~90℃ for hot water meter. .Water pressure : s1.6Mpa (16 bar).
	Operating Condition
	-The Max.Admissible water pressure 1.6MPa. -Resisting water temperature: 50℃.

Dial Picture	Measure Unit
	Measure Unit: CBM 8 WHEELS Four red, four white wheel. The minimum reading: 1L
	Measure Unit: CBM 8 WHEELS Three red,five white wheel. The minimum reading: 1OL
	Measure Unit:UK Gallon 8 WHEELS One red,seven white wheel The minimum reading: 1 UK/Gallon
	Measure Unit:UK Gallon 8 WHEELS All white wheel The minimum reading: 10 UK Gallon
	Measure Unit:US Gallon 8 WHEELS One red,three black,four white wheel The minimum reading: 1 US Gallon
