Water Meter Connector Fitting Water Meter Parts Diagram
Description of water meter connector fitting
Meter cover: 15-600mm
Meter coupling: 15, 20, 25, 32, 40, 50mm (For multi jet & single jet & volumetric)
Meter flange: 50mm-600mm
Lead free meter fitting: 15mm-50mm
Technics: Forging, Casting. ductile
Material: Brass, Plastic, cast iron, ductile iron
BSPT or NPT thread.
Meter mechanism: 15mm-600mm
Meter box
We produce all parts for multi-jet water meter, single-jet water meter, volumetric water meter, Woltman water meter, prepaid water meters etc.
Specifications of the water meter.
Plastic water meter box. good quality and cheap price.
Special locking mechanism , requiring a tailor-made key to open the lid.
Unique coupings, conventient replacement for the meters inside the meter/ballcock assembly is locked where it passes through the meter box to prevent it from rotating during installation.
High quality ball cock shut off valves without rising headparts which can cause leaks.
Standards Compliance
ISO4064 Class B for horizontal installation
Application of water meter
The meter boxes are designed to protect the water meter from unauthorized access and damage the meter boxes are suitable for use in heave traffic situations working conditions
Water temperature: <40C
