Woltman Water Meter With Removable Measuring Insert Class B

It is a in-line helical vane (Woltman) dry type water meter designed to measure the volume of cold water at a pressure to 16 bars for industry or irrigation applications. Installation shall be done in a horizontal position with counter upwards.

Send Inquiry

Hebei Shanghong Meters Technology Co., Ltd. is one of the leading manufacturers and suppliers of woltman water meter with removable measuring insert class b in China. If you're going to wholesale high quality woltman water meter with removable measuring insert class b, welcome to get pricelist and quotation from our factory.

main product

Product Description

APPLICATION
It is a in-line helical vane (Woltman) dry type water meter designed to measure the volume of cold water at a pressure to 16 bars for industry or irrigation applications. Installation shall be done in a horizontal position with counter upwards.

ACCORADANCE WITH RULES
- Class B
- R=80

ADVANTAGES
- Woltman type water meter, dry type register with magnetic transmission.
- Hermetically sealed register, and protected against external magnetic interference.
- Optimum accuracy with very low starting flow rate and pressure loss.
- Removable measuring insert.
- Long-life, low maintenance operation,
- Performance well at all times and in horizontal position.
- Dimensions as per ISO4064.
- The water meter in special edition is equipped with pulse or AMR emitter to connect with AMR system.

ADDITIONAL OPTIONAL
- Copper can register
- T90

AMR TECHNOLOGY
- Pre-equipped with reed-switch for prulse output

DIMENSIONS
- Dimensions as per ISO4064.

ACCESSORIES
- Gaskets

- Manuals
