Woltman Type Detachable Dry Type Water Meter

Specification: Large detachable dry water meter /Woltmann flanged types(R=80) is an inferential,multtistream,dry dial,straight reading type meter for cold water,suitable for domestic use.Brass body and adopt all antiseptic material,no leak,mechanical transmission not effected by external magnetic fields or ferrous particles in water.Accuracy is in accordance with ISO40064,Class B standard.

Send Inquiry

Hebei Shanghong Meters Technology Co., Ltd. is one of the leading manufacturers and suppliers of woltman type detachable dry type water meter in China. If you're going to wholesale high quality woltman type detachable dry type water meter, welcome to get pricelist and quotation from our factory.

Woltman type detachable dry type water meter

woltman water meter (13)

Specification:

Large detachable dry water meter /Woltmann flanged types(R=80) is an inferential,multtistream,dry dial,straight reading type meter for cold water,suitable for domestic use.Brass body and adopt all antiseptic material,no leak,mechanical transmission not effected by external magnetic fields or ferrous particles in water.Accuracy is in accordance with ISO40064,Class B standard.

Woltmann Water Meter Types

We can supply high quality Flanged water meter Woltmann water meterr DN50-300mm with reasonable price ,any comments or needed ,pls feel free to comtact me.

Details for Flanged water meter Woltmann water meterr DN50-500mm

woltman water meter (13)

woltman water meter (11)

SPECIFICATION:

Woltmann water meter is a full helix type,magnetic drive,dry dial water meter with an interchangeable measuring unit.It has the advantages of small resistance,negligible head loss,big capacity,excellent accuracy,high measuring capacity,and long life if service.The measuring unit with sealed indicator offers the meters with very clear reading condition.This series can be equipped with a kind of remote transmission device.The generating volume is 0.3m³/Pulse and 1m³/Pulse.

Features:

1.the material is Environment Friendly

2..warranty: 2 years

3.Supply ability:100000 pcs per month

Application:

--Measuring the volume of cold (hot) water passing through the pipeline.

Feature:

--Removable element structure, easy installation and maintenance, register for universal use within this range detachable

without Removing the meter from the pipeline;

--Dry-dial, Magnetic drive sensitive action, small pressure loss;

--Vacuum sealed register ensures the dial keep free from fog and Keep the reading clear in a long term service;

--Selected high quality materials for steady & reliable characteristic;
