Cast iron Water Meter multi-jet water meter brass body DN15~50mm Water Meter
A multi-jet water meter is a type of mechanical water meter used for measuring water consumption in residential, commercial, and industrial buildings. It is called "multi-jet" because it has multiple points of jet, or directed water flow, which are used to spin the impeller inside the meter. The impeller then measures the flow of water through the meter, and the readings are recorded.
Unlike single-jet water meters, multi-jet water meters can operate with a wide range of flows and tolerate low flows of water, making them an appropriate option for many buildings including apartments or hotels with multiple units that may typically have abrupt changes in the water flow rate.
The multi-jet design utilizes impeller placement to help even out the water flow's force around the impeller, which improves the meter's precision and accuracy. The accuracy of a multi-jet water on low flow velocity can be as high as 98%.
Multi-jet water meters are built to last, constructed with lead-free materials appropriate for use in potable water systems. This improves the longevity of its service life and also reduces the probability of contaminating the water being measured. They can also be equipped with additional features like remote reading systems, pulse output devices or leak detection instruments to enable remote monitoring and alert systems.
Application
home,commercial,municipality,pipeline
Features
·Magnetic shield, for external magnetic field protection.
·Sealed dry register ensures long time clear reading.
·External regulating device.
Accressories: 2pcs coupling, 2pcs coupling nuts and 2pcs washers.
·With high accuracy
·For horizontal use
·Accessories include Strainer, Rotary piston, Connection Widget, connector fitting
Optional Features
·Accuracy: R=80 ; 100; 125; 160;class b;class c.
·Size: 15~50mm.
·Cold water.
·Non return valve.
·Reed switch option.
·Several lengths and connections availavle on request.
·Thread end type: BSP / NPT.
·Materials: Brass,Brass interface,Brass material
·Brass working pressure: PN16(16bar)
·Provide pulse output/rs485 modbus/wired remote/pulse splitter/pulse read display
Maximum Permissible Error
·In the lower zone from qmin inclusive up to but excluding qt is ±5%.
·In the upper zone from qt inclusive up to and including qs is ±2%; ±3% for hot water meter.
Standards Compliance
Working Conditions
·Water pressure: ≤1.6Mpa (16 bar).
|
DN(mm)
|
15
|
20
|
25
|
32
|
40
|
50
|
50
|
|
Size(inch)
|
1/2''
|
3/4''
|
1''
|
1-1/4''
|
1-1/2''
|
2''
|
2''
|
|
Length(L)
|
165/190
|
190
|
260
|
260
|
300
|
300
|
280
|
|
Width(W)
|
99/104
|
98
|
103.5
|
103.5
|
125
|
125
|
160
|
|
Height(H)
|
116/121
|
117
|
124
|
124
|
162
|
162
|
187.5
|
|
Connecting Thread D
|
G3/4B
|
G1B
|
G11/4B
|
G11/2B
|
G2B
|
G21/2B
|
Flange end
|
|
Weigt(kgs)
|
1.65
|
1.79
|
1.85
|
2.68
|
5.25
|
7.25
|
|
|
item
|
value
|
|
Warranty
|
1 year
|
|
Customized support
|
OEM, ODM
|
|
Place of Origin
|
China
|
|
Type
|
Multi-jet meters
|
|
Product name
|
plastic body cold water meter
|
|
Material
|
brass
|
|
temperature
|
Cold Water:0.1-50
|
|
Working pressure
|
WaterTemperature;Water Pressure
|
|
Range ratio
|
R80/R160
|
|
Feature
|
High Performance
|
|
Application
|
Household
|
|
Protection class
|
IP68
|
|
Type
|
dry dial
|
|
Certificate
|
ISO4064
|
