Digital Lora Water Meter Smart Water Meter

·Material: Brass, Cast Iron
·Scenes to be used: garden, commercial, general household, residential building, municipality
·Waterproof level: IP68
·Technical data conform to international standard ISO 4064
·Accuracy: class b·Water temperature: 0.1℃~50℃ ( 0.1℃~90℃ for hot water meter).
·Fitting: Concentrator, Repeater, Connector, PCB, valve control, Strainer, Reading device, Valve actuator, Plastic cover, Battery operated, Coupling, Pointer, Components, Counter, register, Ball valve
·Communication: Lora, wireless remote, local internet, Private Protocol

Send Inquiry

Hebei Shanghong Meters Technology Co., Ltd. is one of the leading manufacturers and suppliers of digital lora water meter smart water meter in China. If you're going to wholesale high quality digital lora water meter smart water meter, welcome to get pricelist and quotation from our factory.

LoRa water meters provide an efficient and convenient solution for remote water metering and monitoring, enabling efficient water management and conservation.

lora wireless water meter main picture

LoRa Water Meters Advantages
1. Wireless Connectivity: LoRa water meters eliminate the need for physical wiring connections, as they communicate wirelessly with a LoRaWAN network. This enables flexible installation and reduces infrastructure costs.
2. Long Range: LoRa technology allows for long-range communication, typically covering several kilometers in urban environments. This makes it suitable for water metering in large areas or remote locations without the need for additional repeaters or infrastructure.
3. Low Power Consumption: LoRa water meters are designed to operate on low power, allowing for long battery life. This reduces maintenance requirements and extends the operational lifespan of the meters.
4. Real-time Data Monitoring: LoRa water meters can provide real-time data on water consumption, enabling utilities or consumers to monitor usage patterns, detect leaks, and optimize water management. This data can be accessed remotely through a LoRaWAN network.
5. Scalability: LoRaWAN networks are designed to support a large number of devices, making it scalable for widespread water meter deployments. Multiple water meters can be connected to a single LoRaWAN gateway, simplifying network management.
6. Cost-effective: LoRa technology offers cost advantages compared to traditional wired communication systems. The reduced infrastructure and installation costs contribute to overall cost savings.

Outline Dimension Drawing

Nominal diameter	15	20	25
Length L	258	299	345
Length L1	165	195	225
Width B	90	90	90
Height H1	112	112	114
Height H2	184	184	186
Max flow Q4 (m3/h)	3.125	5	7.87
Nominal flow Q3 (m3/h)	2.5	4	6.3
Transitional flow Q2 (m3/h)	0.05	0.08	0.2
Min flow Q1 (m3/h)	0.031	0.05	0.07
Accuracy class	Class B
Working temperature	0.1~30 ºC
Working pressure:	≤1.0MPa
Pressure loss	≤0.063MPa
Protection grade	IP68
Installation environment:	Class B
Flow profile sensitivity level	U10, D5
